topic-35170

Posts: 8515

Joined: Tue Dec 20, 2005 07:36 PM

Re: Mr. Rao's samples collection.
Posted: Wed Feb 07, 2018 05:11 PM

Uwe,

Application
===========
   Path and name: C:\Forum4\TEST\XBRWTEST.exe (32 bits)
   Size: 3,504,640 bytes
   Compiler version: xHarbour 1.2.3 Intl. (SimpLex) (Build 20170215)
   FiveWin  version: FWHX 17.01
   C compiler version: Borland/Embarcadero C++ 7.2 (32-bit)
   Windows version: 6.1, Build 7601 Service Pack 1

   Time from start: 0 hours 0 mins 0 secs
   Error occurred at: 07/02/2018, 15:08:28
   Error description: Error BASE/1068  Argument error: array access
   Args:
     [   1] = N   16371319
     [   2] = N   1

Stack Calls
===========
   Called from: .\source\classes\BAR.PRG => GRADIENTFILL( 1250 )
   Called from: .\source\classes\BRUSH.PRG => GRADIENTBMP( 578 )
   Called from: .\source\classes\BRUSH.PRG => TBRUSH:RESIZE( 516 )
   Called from: .\source\classes\WINDOW.PRG => TDIALOG:PAINTBACK( 2488 )
   Called from: .\source\classes\DIALOG.PRG => TDIALOG:ERASEBKGND( 729 )
   Called from:  => TWINDOW:HANDLEEVENT( 0 )
   Called from: .\source\classes\DIALOG.PRG => TDIALOG:HANDLEEVENT( 914 )
   Called from:  => DIALOGBOXINDIRECT( 0 )
   Called from: .\source\classes\DIALOG.PRG => TDIALOG:ACTIVATE( 296 )
   Called from: .\XBRWTEST.PRG => MAIN( 232 )

João Santos - São Paulo - Brasil - Phone: +55(11)95150-7341

ukoenig

Posts: 4043

Joined: Wed Dec 19, 2007 06:40 PM

Re: Mr. Rao's samples collection.
Posted: Wed Feb 07, 2018 05:18 PM

Thank You very much,
I will have a look at it maybe something is left from the defines of the original

the source for XBRWTEST.exe is included

It means just add or change anything You like.
If you like to change the colours You can do it in the original < Setup >
after the changes copy the SYSTEM.dbf to the testfolder
XBRWTEST is only included to check and solve any problems

regards
Uwe

Since 1995 ( the first release of FW 1.9 )

i work with FW.

If you have any questions about special functions, maybe i can help.

karinha

Posts: 8515

Joined: Tue Dec 20, 2005 07:36 PM

Re: Mr. Rao's samples collection.
Posted: Wed Feb 07, 2018 05:35 PM

Thanks Uwe, changed nStyle := 1 in DLG_BACK. Many thanks.

João Santos - São Paulo - Brasil - Phone: +55(11)95150-7341

ukoenig

Posts: 4043

Joined: Wed Dec 19, 2007 06:40 PM

Re: Mr. Rao's samples collection.
Posted: Wed Feb 07, 2018 05:40 PM

The colors are defined in SYSTEM.dbf

static aVal[32]

SYSTEM->nDStyle = color, gradient, circle or bmp-brush
SYSTEM->nDColorF = 1. gradient-color
SYSTEM->nDColorB = 2. gradient-color
SYSTEM->nDGradPos = gradient-pos
SYSTEM->lDDirect = vertical or horizontal
SYSTEM->cDBrush = bmp brush
SYSTEM->nBSColor = xbrowse-selector
SYSTEM->nBRColor1= 1. row color
SYSTEM->nBRColor2 = 2. row color
SYSTEM->nBRColor3
SYSTEM->nBRColor4
SYSTEM->nBRColor5

FUNCTION READ_SYS(lStart, oTopic, oLink, oTCode, oForum)
LOCAL I, J, X, nAuthorPos := 1

SYSTEM->(DBGOTOP())

IF lStart = .F.
aVal[20] := SYSTEM->nDStyle
aVal[21] := SYSTEM->nDColorF
aVal[22] := SYSTEM->nDColorB
aVal[23] := SYSTEM->nDGradPos
aVal[24] := SYSTEM->lDDirect
aVal[25] := SYSTEM->cDBrush
aVal[26] := SYSTEM->nBSColor
aVal[27] := SYSTEM->nBRColor1
aVal[28] := SYSTEM->nBRColor2
aVal[29] := SYSTEM->nBRColor3
aVal[30] := SYSTEM->nBRColor4
aVal[31] := SYSTEM->nBRColor5
ENDIF...

Dialog-background
DLG_BACK( oDlg, aVal[20], aVal[21], aVal[22], aVal[24], aVal[23], aVal[25] ) )
You can define values instead of using the vars from SYSTEM.dbf

that is funny

Error description: Error BASE/1068 Argument error: array access

Args:
[ 1] = N 16371319
[ 2] = N 1

Stack Calls
===========
Called from: .\XBRWTEST.PRG => MAIN( 232 )

regards
Uwe

Since 1995 ( the first release of FW 1.9 )

i work with FW.

If you have any questions about special functions, maybe i can help.

karinha

Posts: 8515

Joined: Tue Dec 20, 2005 07:36 PM

Re: Mr. Rao's samples collection.
Posted: Wed Feb 07, 2018 05:45 PM

Code (fw): Select all Collapse

aVal[20]    := SYSTEM->nDStyle  -> with 3 no work. With 1 work fine. Thanks Uwe.

Regards,

João Santos - São Paulo - Brasil - Phone: +55(11)95150-7341

ukoenig

Posts: 4043

Joined: Wed Dec 19, 2007 06:40 PM

Re: Mr. Rao's samples collection.
Posted: Wed Feb 07, 2018 05:59 PM

nStyle 3 is Circle-painting and new

I think Your FWH-version doesn't support it.

circle syntax
IF nStyle = 3 // GRADIENT CIRCLE
aGrad := { nColor1,nColor2 }
DEFINE BRUSH oBrush GRADIENT aGrad
ENDIF

regards
Uwe

Since 1995 ( the first release of FW 1.9 )

i work with FW.

If you have any questions about special functions, maybe i can help.

karinha

Posts: 8515

Joined: Tue Dec 20, 2005 07:36 PM

Re: Mr. Rao's samples collection.
Posted: Wed Feb 07, 2018 06:24 PM

ukoenig wrote:nStyle 3 is Circle-painting and new

I think Your FWH-version doesn't support it.

circle syntax
IF nStyle = 3 // GRADIENT CIRCLE
aGrad := { nColor1,nColor2 }
DEFINE BRUSH oBrush GRADIENT aGrad
ENDIF

regards
Uwe

Thank you Uwe. Probably my version of FWH1701 that does not support the command. Many thanks. Regards.

João Santos - São Paulo - Brasil - Phone: +55(11)95150-7341

ukoenig

Posts: 4043

Joined: Wed Dec 19, 2007 06:40 PM

Re: Mr. Rao's samples collection.
Posted: Wed Feb 07, 2018 06:33 PM

Yes it is included later
You can test the circle in the main-app button < Setup >

I just found a little bug in changing a file and selecting the area
It is ok now

because of all the new included options I will explain the usage and possibilities in detail the next time.

Download :

http://www.service-fivewin.de/DOWNLOADS/Forum4.zip

regards
Uwe

Since 1995 ( the first release of FW 1.9 )

i work with FW.

If you have any questions about special functions, maybe i can help.

karinha

Posts: 8515

Joined: Tue Dec 20, 2005 07:36 PM

Re: Mr. Rao's samples collection.
Posted: Wed Feb 07, 2018 06:51 PM

Perfect!! Many thanks.

Regards,

João Santos - São Paulo - Brasil - Phone: +55(11)95150-7341

ukoenig

Posts: 4043

Joined: Wed Dec 19, 2007 06:40 PM

Re: Mr. Rao's samples collection.
Posted: Wed Feb 07, 2018 09:04 PM

João,

I added some more options from the main-program to the test-source
like the download range
just download again.

regards
Uwe

Since 1995 ( the first release of FW 1.9 )

i work with FW.

If you have any questions about special functions, maybe i can help.

Marc Venken

Posts: 1487

Joined: Tue Jun 14, 2016 07:51 AM

Re: Mr. Rao's samples collection.
Posted: Thu Feb 08, 2018 08:34 AM

Hey Uwe,

For the Xbrowse header index :

I noticed that when you select a other file (example ..) AND you hit the reindex key, than the indexes work again on the headers.

In the Prg the function is not included, but maybe you have to look there for a solution.

Marc Venken

Using: FWH 23.08 with Harbour

ukoenig

Posts: 4043

Joined: Wed Dec 19, 2007 06:40 PM

Re: Mr. Rao's samples collection.
Posted: Thu Feb 08, 2018 08:54 AM

Marc,

it is not a real reindex it is a clean reset.
All what I do is closing all areas and deleting the indexfiles.
Next I force a < restart >
There is a small program < restart.exe > from Daniel included.
Because of the missing indexfiles they are new created.

For a test You can include the button in < xBrwtest.prg >
and copy < Restart.exe > from the main-directory to the test-directory.

How it works :

1. save all vars to SYSTEM.dbf
2. close all open areas
3. delete the indexfiles
4. restart

like You can see every position and all values are saved
and the screen looks exactly the same like before.
You can use this little tool for other situations as well.

Code (fw): Select all Collapse

@ 600, 1040 BTNBMP oBtn[11] OF oDlg ;
SIZE 75, 40 PIXEL 2007 ; // B / H
PROMPT " &Re-" + CRLF + "index " ;
ACTION ( [color=#0000FF]SAVE_END(), DEL_INDEX(), WINEXEC( "restart xBrwtest.exe " + Str( oDlg:hWnd ) , 0 ) [/color]) ;
FILENAME c_path1 + "RESET.bmp" ;
LEFT

// -----------------------------------

FUNCTION SAVE_END()
LOCAL I := 1, X := "1"

SYSTEM->(DBGOTOP())
FOR I := 1 TO 7
   X := LTRIM(STR(I))
   IF nFilename = I
      SYSTEM->(RLOCK())
      SYSTEM->nTForum&X := nForum
      SYSTEM->nTSelect&X := nTSelect
      SYSTEM->nTRecord&X := nGoRecord
    ENDIF
    SYSTEM->nSample := nFilename
    SYSTEM->(DBCOMMIT())
    SYSTEM->(DBUNLOCK())
NEXT

RETURN NIL

// -------------------

FUNCTION DEL_INDEX()

CLOSE DATABASE

DELETE FILE ( c_Path + "Samples1.cdx" )
DELETE FILE ( c_Path + "Samples2.cdx" )
DELETE FILE ( c_Path + "Samples3.cdx" )
DELETE FILE ( c_Path + "Samples4.cdx" )
DELETE FILE ( c_Path + "Samples5.cdx" )
DELETE FILE ( c_Path + "Samples6.cdx" )
DELETE FILE ( c_Path + "Samples7.cdx" )

RETURN NIL

regards
Uwe

Since 1995 ( the first release of FW 1.9 )

i work with FW.

If you have any questions about special functions, maybe i can help.

ukoenig

Posts: 4043

Joined: Wed Dec 19, 2007 06:40 PM

Re: Mr. Rao's samples collection.
Posted: Mon Feb 12, 2018 07:12 PM

I finished the translation part..
Now You can translate the mainscreen-text ( says and buttons )
just overwrite the english text and save.
The english text can be restored.

For the xBrowsetest I included my network-tools as a OBJ-file.
If You dont like it You can replace the section with the normal rlock(), unlock() ....

// ---------- NET - FUNCTIONS ---------

// NET_USE ( cFileName, cAlias, nTrials, nTime, lNet )
// NET_RLOCK( nTrials, nTime )
// NET_ULOCK()
// NET_WAIT ( nTrials, nTime )
// NET_DELETE ( nSeconds )
// NET_RECALL ( nSeconds )
// NET_APPEND ( nTrials, nTime )
// NET_PACK( cDBName, cAlias, nTrials, nTime, lNet, lQuite )
// lNet = shared, exclusive
// lQuite = .T. asks if packing is wanted
// nTrials = in case of a error, how often to try
// nTime = message delay
// NET_CLOSE( nTrials, nTime )

As long we cannot connect to a defined forum, You can use the flag-selection as a visual file-splitting
Until now I couldn't detect the reason for the xbrowse seek-problems on filechange.
On restart ( index-rebuild ) it works.

Download :
http://www.service-fivewin.de/DOWNLOADS/Forum5.zip

regards
Uwe

Since 1995 ( the first release of FW 1.9 )

i work with FW.

If you have any questions about special functions, maybe i can help.

Marc Venken

Posts: 1487

Joined: Tue Jun 14, 2016 07:51 AM

Re: Mr. Rao's samples collection.
Posted: Mon Feb 12, 2018 08:01 PM

Uwe,

Why are there 2 versions ?

The Prg. Is the a full version?

The new version has no yellow seek bar.

Marc Venken

Using: FWH 23.08 with Harbour

ukoenig

Posts: 4043

Joined: Wed Dec 19, 2007 06:40 PM

Re: Mr. Rao's samples collection.
Posted: Mon Feb 12, 2018 08:16 PM

Marc,

xBrowsetest is only a version ( small in size ) to help to solve any problems.
The service-section is not included.
It is not everything included like in forum.exe ( full ).
The PRG's are included just to show the logic and for testing.

regards
Uwe

Since 1995 ( the first release of FW 1.9 )

i work with FW.

If you have any questions about special functions, maybe i can help.
