I have a dialog with a button bar built in. ( using tBar control in the resource file ).

I DEFINE BUTTONBAR ...no problem
I DEFINE BUTTON ... no problem

Add in GROUP LABEL "xyz" to some buttons ... works fine.

My last two buttons are a help button and an exit button. BTNRIGHT and they go to where they are placed.

So here is the issue. On the last GROUP LABEL, I would like to put a separator since there is a lot of space to the right on the label line. It would allow better centering of the label on the item(s) in that group.

Also, I use no label on the last two buttons, with BTNRIGHT, but a separator appears on the label line between them. I would love to not have that separator.

Any thoughts ?

Hello Tim
do you know if you can draw the TABs instead of diagonally also vertically.
Thank you in advance
Otto

Otto wrote:Hello Tim
do you know if you can draw the TABs instead of diagonally also vertically.
Thank you in advance
Otto

Exactly, and thank you.

Mr. Otto

Sorry, that is not possible.

Hello Silvio,

yes this is what I would like to have.
But maybe I can use buttons to achieve the goal.
Thank you and best regards
Otto

TimStone wrote:Exactly, and thank you.

   DEFINE BUTTONBAR oBar OF oWnd SIZE 48,64 2007  HEIGHT 90
   DEFINE BUTTON OF oBar PROMPT "One"  GROUP LABEL "FIRST" COLORS CLR_WHITE,CLR_GREEN
   DEFINE BUTTON OF oBar PROMPT "Two"
   DEFINE BUTTON OF oBar PROMPT "Three"
   DEFINE BUTTON OF oBar PROMPT "Four" GROUP LABEL "SECOND" COLORS CLR_WHITE,CLR_BLUE
   DEFINE BUTTON OF oBar PROMPT "Five"

   DEFINE BUTTON OF oBar PROMPT "Info" BTNRIGHT GROUP LABEL "INFO" COLORS CLR_WHITE,CLR_BLUE
   DEFINE BUTTON OF oBar PROMPT "Help" BTNRIGHT GROUP LABEL "LAST" COLORS CLR_WHITE,CLR_GREEN
   DEFINE BUTTON OF oBar PROMPT "Exit" BTNRIGHT

nageswaragunupudi wrote:

TimStone wrote:Exactly, and thank you.

Implemented in FWH1808

Code (fw): Select all Collapse

   DEFINE BUTTONBAR oBar OF oWnd SIZE 48,64 2007  HEIGHT 90
   DEFINE BUTTON OF oBar PROMPT "One"  GROUP LABEL "FIRST" COLORS CLR_WHITE,CLR_GREEN
   DEFINE BUTTON OF oBar PROMPT "Two"
   DEFINE BUTTON OF oBar PROMPT "Three"
   DEFINE BUTTON OF oBar PROMPT "Four" GROUP LABEL "SECOND" COLORS CLR_WHITE,CLR_BLUE
   DEFINE BUTTON OF oBar PROMPT "Five"

   DEFINE BUTTON OF oBar PROMPT "Info" BTNRIGHT GROUP LABEL "INFO" COLORS CLR_WHITE,CLR_BLUE
   DEFINE BUTTON OF oBar PROMPT "Help" BTNRIGHT GROUP LABEL "LAST" COLORS CLR_WHITE,CLR_GREEN
   DEFINE BUTTON OF oBar PROMPT "Exit" BTNRIGHT
