Mr. Rao, Pls your help
Posted: Sun Jul 07, 2024 11:53 PM

Mr. Rao:

I need your valuable help to build a TREE on a BROWSE, I have a table with the following structure

    cCmdSql := "CREATE TABLE IF NOT EXISTS Cierre(" +;
                  "CIE_NI1 DECIMAL(02,0)       NOT NULL DEFAULT 0               COMMENT 'Primer nivel'," +;
                  "CIE_NI2 DECIMAL(02,0)       NOT NULL DEFAULT 0               COMMENT 'Segundo nivel'," +;
                  "CIE_NI3 DECIMAL(02,0)       NOT NULL DEFAULT 0               COMMENT 'Tercer nivel'," +;
                  "CIE_NI4 DECIMAL(02,0)       NOT NULL DEFAULT 0               COMMENT 'Cuarto nivel'," +;
                  "CIE_NI5 DECIMAL(02,0)       NOT NULL DEFAULT 0               COMMENT 'Quinto nivel'," +;
                  "CIE_DES VARCHAR(70)         NOT NULL DEFAULT ''              COMMENT 'Cierre de proyecto'," +;
                  "CIE_PRE DECIMAL(15,2)       NOT NULL DEFAULT 0.00            COMMENT 'Presupuesto'," +;
                  "CIE_GAS DECIMAL(15,2)       NOT NULL DEFAULT 0.00            COMMENT 'Gastado'," +;
                  "CIE_DIF DECIMAL(15,2)       NOT NULL DEFAULT 0.00            COMMENT 'Diferencia'," +;
                  "PRIMARY KEY(CIE_NI1,CIE_NI2,CIE_NI3,CIE_NI4,CIE_NI5))" +;
                  "ENGINE = InnoDB                                                 COMMENT 'Cierre de proyecto';"

The TREE must be built by the first 5 fields (CIE1,CIE2,CIE3,CIE4,CIE5),
and in the end be able to print it exactly as the branches are, open or closed

I have seen the examples\tree.prg but it is built with arrays.

If you have time to help me, I will send you the CIERRE table full of records

Here is an image of the content of the CIERRE table

Your help will be greatly appreciated.

Best regards

SOI, s.a. de c.v.
estbucarm@gmail.com
http://www.soisa.mex.tl/
http://sqlcmd.blogspot.com/
Tel. (722) 174 44 45
Carpe diem quam minimum credula postero

Otto

Posts: 6983

Joined: Fri Oct 07, 2005 07:07 PM

Re: Mr. Rao, Pls your help
Posted: Mon Jul 08, 2024 07:18 AM

Dear Armando,

I use
:bIndent := { ||20 + ( ::cAlias )->TREELEVEL * 20 } .
With this it is easy to reach what you want.
:bIndent block and original xBrowse is much more flexible .

I called the program RAO-notes at the time. It was an abbreviation:

>Discover a new dimension of working with your information. RAO Notes: RAPID AND ORGANISED NOTES<

But in reality, I just wanted to thank Mr. Rao, who helped me a lot with it.

Best regards,
Otto
This program is from 2011! Back then, we tried very hard to achieve the Metrostyle and Windows 8 look and feel.

nageswaragunupudi

Posts: 10733

Joined: Sun Nov 19, 2006 05:22 AM

Re: Mr. Rao, Pls your help
Posted: Mon Jul 08, 2024 08:50 AM

If you have time to help me, I will send you the CIERRE table full of records

Please connect to our FWH server

Code (fw): Select all Collapse

oCn := maria_Connect( "208.91.198.197:3306,fwhdemo,gnraofwh,Bharat@1950", .t. )

and create your table on this server and let us know.

Regards

G. N. Rao.

Hyderabad, India

Armando

Posts: 3358

Joined: Fri Oct 07, 2005 08:20 PM

Re: Mr. Rao, Pls your help
Posted: Mon Jul 08, 2024 03:29 PM

Mr. Rao:

The table is already on your server, its name is CIERRE

Best regards

SOI, s.a. de c.v.
estbucarm@gmail.com
http://www.soisa.mex.tl/
http://sqlcmd.blogspot.com/
Tel. (722) 174 44 45
Carpe diem quam minimum credula postero

Armando

Posts: 3358

Joined: Fri Oct 07, 2005 08:20 PM

Re: Mr. Rao, Pls your help
Posted: Wed Jul 10, 2024 09:30 PM

Mr Otto:

Thanks so much.

Regards

Otto wrote:Dear Armando,

I use
:bIndent := { ||20 + ( ::cAlias )->TREELEVEL * 20 } .
With this it is easy to reach what you want.
:bIndent block and original xBrowse is much more flexible .

I called the program RAO-notes at the time. It was an abbreviation:

>Discover a new dimension of working with your information. RAO Notes: RAPID AND ORGANISED NOTES<

But in reality, I just wanted to thank Mr. Rao, who helped me a lot with it.

Best regards,
Otto
This program is from 2011! Back then, we tried very hard to achieve the Metrostyle and Windows 8 look and feel.

SOI, s.a. de c.v.
estbucarm@gmail.com
http://www.soisa.mex.tl/
http://sqlcmd.blogspot.com/
Tel. (722) 174 44 45
Carpe diem quam minimum credula postero

Marc Venken

Posts: 1487

Joined: Tue Jun 14, 2016 07:51 AM

Re: Mr. Rao, Pls your help
Posted: Thu Jul 11, 2024 07:03 AM

Otto,

You have a link to the post for the Rao-Notes ?

Marc Venken

Using: FWH 23.08 with Harbour
