            // BARRA DE BUSQUEDA EN LA CABECERA DEL BROWSE (Multiples columnas de busquedas)
            :lGetBar             := .T.                                       // Para usar la barra de busqueda se debe poner en TRUE
            :nGetBarHeight       := 35                                        // Altura en pixel de la barra de Busqueda
            :bClrEdits           := { || { CLR_BLACK,rgb(255,250,240) } }     // Color de fondo en la barra de busqueda cuando toma el foco
            //----------------------------------------------------------------------------
            WITH OBJECT :Codigo
                 :cSortOrder    := "articulos.codigoarticulo"
                 :Cargo         := "articulos.codigoarticulo"
                 :cBarGetPic    := "@ 99999999999"
                 :uBarGetVal    := 0
                 :cBarGetBmp    := "BRW_CLEAR"
                 :bBarGetAction := <||
                                       ::oBrw:Codigo:uBarGetVal:=0
                                       ::SetFilterRegistro(::oBrw,"Limpiar")
                                       Return Nil
                                   >    // Busqueda pulsando el boton que le pongamos
                 :bBarGetValid  := <|x|
                                       ::SetFilterRegistro(::oBrw,"Filtrar")
                                       Return .T.
                                   >    // Busqueda pulsando el ENTER

             ///:bClrStd := {|| {CLR_BLACK, RGB(223,197,255)} }
             :bClrStd := {|| {CLR_BLACK, VAL(::oApp:colorFondoCelda["ArtSis"]) }}  //RGB(223,197,255)}

        ENDWITH
        //----------------------------------------------------------------------------

diff --git a/source/classes/xbrowse.prg b/source/classes/xbrowse.prg
index 089a6d6a6..e3a6e0ec9 100644
--- a/source/classes/xbrowse.prg
+++ b/source/classes/xbrowse.prg
@@ -13475,6 +13475,7 @@ CLASS TXBrwColumn
    METHOD CreateBarGet()
    METHOD ShowSeek( lOn )
    METHOD CheckBarGet( lOn )
+   METHOD PlaceBarGetBtn()
    METHOD PostEdit( xValue, lButton, lDirectAssign, nLbxAt )

    METHOD SetCheck( aBmps, uEdit, aPrompts )
@@ -16342,12 +16343,34 @@ METHOD CreateBarGet() CLASS  TXBrwColumn
    @ 0,0 CHECKBOX ::oBarGet VAR ::uBarGetVal PROMPT "" SIZE 16,16 PIXEL OF ::oBrw
    else
    lRight      := ( ValType( ::uBarGetVal ) $ 'NDT' )
+    // Create the GET WITHOUT a button (pass nil for bAction and cBmpName).
+    // If the button were created here, TGet:New() builds it while the GET is
+    // still 10x10 (a tiny, top-left, transparent custom-paint button that the
+    // GET draws itself). Resizing the GET later in CheckBarGet() cannot undo
+    // that initial paint, so the button stays small at the top-left corner.
+    // Instead we create a single, normal (non-transparent) button afterwards
+    // and let CheckBarGet() size/position it square on the right of the GET.
    ::oBarGet   := TGet():New( 0, 0, { |x| If( x == nil, ::uBarGetVal, ::uBarGetVal := x ) }, ;
       ::oBrw, 10, 10, ::cBarGetPic, ::bBarGetValid, aColors[ 1 ], aColors[ 2 ], ;
       ::HeaderFont, nil, nil, .t., nil, .t., nil, nil, lRight, ;
       nil, .f., .f., nil, nil, .f.,;
-      nil, nil, nil, nil, ::bBarGetAction, ::cBarGetBmp, nil,;
+      nil, nil, nil, nil, nil, nil, nil,;
       nil, nil, ::oBrw:lLimitChars )
+    if ::bBarGetAction != nil
+    ::oBarGet:bAction         := ::bBarGetAction
+    ::oBarGet:cBmpName        := ::cBarGetBmp
+    ::oBarGet:lAdjustBtn      := .f.
+    ::oBarGet:lBtnTransparent := .t.
+    ::oBarGet:CreateButton()
+    if ::oBarGet:oBtn != nil
+    // TBtnBmp:Display() calls CalcSize() on every paint, which restores the
+    // button to its design rect (its bitmap-derived size, top-left of the GET).
+    // That silently undoes the square/right-side placement done in CheckBarGet
+    // on the next repaint. Clearing aSizeRect disables that auto-resize so the
+    // explicit geometry sticks.
+    ::oBarGet:oBtn:aSizeRect := nil
+    endif
+    endif
    ::oBarGet:bKeyChar := { |k,f,o| ( f ), If( k == VK_TAB .or. k == VK_RETURN, ;
       ( If( o:lValid(), ::oBrw:SetFocus(), o:SetFocus() ), 0 ), nil ) }  //FWH17.07
    endif
@@ -16387,12 +16410,17 @@ METHOD CheckBarGet( lOn ) CLASS  TXBrwColumn
    if :IsKindOf( "TCHECKBOX" )
    nCol  := ::nDisplayCol + Int( ( ::nWidth - 16 ) / 2 )
    :Move( nRow, nCol, 16, 16, .t. )
-   elseif :nTop != nRow .or. :nLeft != nCol .or. :nWidth != ( ::nWidth - 8 )
+   else
+   if :nTop != nRow .or. :nLeft != nCol .or. :nWidth != ( ::nWidth - 8 )
    :Move( nRow, nCol, ::nWidth - 4 - 4, ::oBrw:nGetBarHeight - 4, .t. )
    :Refresh()
-   if :IsKindOf( "TGET" ) .and. :oBtn != nil
-   :oBtn:Move( 1, :nWidth - :nHeight, Max( :oBtn:nWidth, :nHeight ), :nHeight - 2, .t. )
    endif
+   // Reposition the button on every check (not only when the GET itself is
+   // re-moved): some events reset the GET's button back to its creation size
+   // at the top-left corner after CheckBarGet() ran, and the GET-move guard
+   // above would otherwise skip restoring it. Geometry is derived from the
+   // column width and bar height, not the GET's (unreliable) ivars.
+   ::PlaceBarGetBtn()
    if :IsKindOf( "TCOMBOBOX" )
    //   :SendMsg( CB_SETITEMHEIGHT, -1, ::oBrw:nGetBarHeight - 4 )
    endif
@@ -16413,14 +16441,7 @@ METHOD CheckBarGet( lOn ) CLASS  TXBrwColumn
    :Show()
    :Enable()
    :Refresh()
-   if :IsKindOf( "TGET" ) .and. :oBtn != nil
-   if IsAppThemed() // 2020-04-26
-   // http://forums.fivetechsupport.com/viewtopic.php?f=3&t=38828
-   :oBtn:Move( -1, :nWidth - :nHeight - 4, Max( :oBtn:nWidth, :nHeight ), :nHeight - 2, .f. )
-   else
-   :oBtn:Move( 1,  :nWidth - :nHeight,     Max( :oBtn:nWidth, :nHeight ), :nHeight - 2, .f. )
-   endif
-   endif
+   ::PlaceBarGetBtn()
    if :IsKindOf( "TCOMBOBOX" )
    //   :SendMsg( CB_SETITEMHEIGHT, -1, ::oBrw:nGetBarHeight - 4 )
    endif
@@ -16438,6 +16459,22 @@ return nil

 //----------------------------------------------------------------------------//

+METHOD PlaceBarGetBtn() CLASS TXBrwColumn
+
+   local nSide
+
+   if ::oBarGet != nil .and. ::oBarGet:IsKindOf( "TGET" ) .and. ;
+      ::oBarGet:oBtn != nil
+      // Square button, full GET height, flush on the right side of the GET.
+      nSide := ::oBrw:nGetBarHeight - 4
+      ::oBarGet:oBtn:Move( 0, ( ::nWidth - 8 ) - nSide, nSide, nSide, .f. )
+      ::oBarGet:oBtn:Show()
+   endif
+
+return nil
+
+//----------------------------------------------------------------------------//
+
 METHOD ShowSeek( lOn ) CLASS  TXBrwColumn

    local nRow, nCol, nBottom, nRight

#include "fivewin.ch"

REQUEST DBFCDX

//----------------------------------------------------------------------------//

function Main()

   SET DATE ITALIAN
   SET CENTURY ON
   SET DELETED ON
   RDDSETDEFAULT( "DBFCDX" )
   SetGetColorFocus()

   Sample1()

return nil

//----------------------------------------------------------------------------//

static function Sample1()

   local oDlg, oBrw, oFont, oBold
   local n, oTmpGet

   USE CUSTOMER NEW SHARED

   DEFINE FONT oFont NAME "TAHOMA" SIZE 0,-12
   DEFINE FONT oBold NAME "TAHOMA" SIZE 0,-12 BOLD

   DEFINE DIALOG oDlg SIZE 800,550 PIXEL TRUEPIXEL ;
      FONT oFont TITLE FWVERSION + " : Bar Get with ACTION Buttons"

   @ 110,20 XBROWSE oBrw SIZE -20,-20 PIXEL OF oDlg ;
      DATASOURCE "CUSTOMER" AUTOCOLS CELL LINES NOBORDER

// --- Relevant Code: Bar GETs with ACTION buttons ---
 for n := 1 to Len( oBrw:aCols )
    WITH OBJECT oBrw:aCols[ n ]
       if FieldType( n ) != 'L'
          :uBarGetVal    := uValBlank( fieldGet( n ) )
          if FieldType( n ) == 'N'
             :cBarGetPic := NumPict( FieldLen( n ), FieldDec( n ) )
          endif
          // Clear button on every column GET
          :cBarGetBmp    := "..\..\..\bitmaps\16back.bmp"
          :bBarGetAction := {|oGet| ;
             ( oTmpGet := oGet,;
               n := AScan( oBrw:aCols, {|c| c:oBarGet == oTmpGet } ),;
               oBrw:aCols[ n ]:uBarGetVal := uValBlank( fieldGet( n ) ),;
               oGet:Refresh(),;
               oBrw:SetFocus() ) }
       endif
    END
 next
   oBrw:lGetBar   := .t.
   // --- End of Relevant Code ---

   WITH OBJECT oBrw
      :nHeaderHeight    := 40
      :oHeaderFonts     := oBold
      :bClrEdits        := { || { CLR_BLACK, RGB( 255, 250, 240 ) } }
      :AutoFit()
      //
      :CreateFromCode()
   END

   @ 10,20 SAY "Bar GETs with ACTION buttons (bitmap on the right side of each GET)." + CRLF + ;
      "Click the arrow button to clear the GET value. Then use Set Filter." + CRLF + ;
      CRLF + ;
      "Usage:  :cBarGetBmp    := '16BACK'" + CRLF + ;
      "        :bBarGetAction := { || ... }" ;
      SIZE oDlg:nWidth - 40,60 PIXEL OF oDlg CENTER

   @ 70, 20 BTNBMP PROMPT { || If( oBrw:lGetBar, "Hide GetBar", "Show GetBar" ) } ;
      SIZE 100,40 PIXEL OF oDlg FLAT ;
      ACTION ( oBrw:lGetBar := ! oBrw:lGetBar, oBrw:Refresh() )

   @ 70,140 BTNBMP PROMPT "Set Filter" ;
      SIZE 100,40 PIXEL OF oDlg FLAT ;
      ACTION ( oBrw:cAlias )->( SetFilter( oBrw ) )

   @ 70,250 BTNBMP PROMPT "Clear Filter" ;
      SIZE 100,40 PIXEL OF oDlg FLAT ;
      ACTION ( oBrw:cAlias )->( DBCLEARFILTER(), oBrw:Refresh(), oBrw:SetFocus() )

   ACTIVATE DIALOG oDlg CENTERED
   RELEASE FONT oFont, oBold

return nil

//----------------------------------------------------------------------------//

static function SetFilter( oBrw )

   local cFilter := ""
   local n, oCol, uVal, cType

   for n := 1 to Len( oBrw:aCols )
      oCol  := oBrw:aCols[ n ]
      if ! Empty( uVal := oCol:uBarGetVal )
         if !Empty( cFilter )
            cFilter  += " .AND. "
         endif
         cType    := ValType( uVal )

     do case
     case cType == 'C'
        uVal     := Upper( AllTrim( uVal ) )
        cFilter += '"' + uVal + '" $ UPPER( ' + FieldName( n ) + " )"
     otherwise
        cFilter  += FieldName( n ) + " == " + cValToChar( uVal )
     endcase
  endif

   next

   if Empty( cFilter )
      if ! Empty( DBFILTER() )
         DBCLEARFILTER()
         oBrw:Refresh()
      endif
   else
      if !( DBFILTER() == cFilter )
         SET FILTER TO &cFilter
         GO TOP
         oBrw:Refresh()
      endif
   endif

   oBrw:SetFocus()

return nil

//----------------------------------------------------------------------------//
