I just tried that, it actually moves the problem back to where I started before making the suggested change to attach to oRb instead of oWnd. It paints incorrectly and nothing is clickable whether using oRb or oWnd.
Here is the sample code you provided, edited to show the situation. It adds MDI to the windows definition, it adds the button bar attaching to oRb, and it adds and explicitly assigns the values oRb:nTopMargin := 50 and oRb:nTop in SetRibbonBarTheme()
#include "FiveWin.ch"
#define RB_THEME_DARK 6
#define COLOR_GRAYTEXT 17
//----------------------------------------------------------------------------//
function Main()
local oWnd
DEFINE WINDOW oWnd MDI
oWnd:SetSize( 1200, 800 )
BuildRibbon( oWnd )
ACTIVATE WINDOW oWnd CENTER // MAXIMIZED
return nil
//----------------------------------------------------------------------------//
function BuildRibbon( oWnd )
local oRb := TRibbonBar():New( oWnd ), oGroup, oBtn, oBar
DEFINE BUTTONBAR oBar SIZE 26, 26 _3D _2010 OF oRb // oWnd
DEFINE BUTTON OF oBar ;
RESOURCE "..\bitmaps\32x32\open.bmp" ;
FLAT TOOLTIP "Hello world." ;
ACTION ( MsgInfo( "Hello world.") )
oGroup = oRb:AddGroup( 185, "First", 1 )
oBtn = oGroup:AddButton( 3, 3, oGroup:nHeight - 19, 90, "One", { || MsgInfo( "One" ) } )
oBtn:LoadBitmaps( "..\bitmaps\32x32\new.bmp" )
oBtn = oGroup:AddButton( 3, oBtn:nWidth + 3, oGroup:nHeight - 19, 90, "Two", { || MsgInfo( "Two" ) } )
oBtn:LoadBitmaps( "..\bitmaps\32x32\open.bmp" )
oGroup = oRb:AddGroup( 185, "Second", 1 )
oBtn = oGroup:AddButton( 3, 3, oGroup:nHeight - 19, 90, "Three" )
oBtn:LoadBitmaps( "..\bitmaps\32x32\setup.bmp" )
oBtn = oGroup:AddButton( 3, oBtn:nWidth + 3, oGroup:nHeight - 19, 90, "Four" )
oBtn:LoadBitmaps( "..\bitmaps\32x32\quit.bmp" )
oRb:AddGroup( 185, "Third", 1 )
SetRibbonBarTheme( oRb, RB_THEME_DARK )
return oRb
//----------------------------------------------------------------------------//
function SetRibbonBarTheme( oRb, nTheme )
local oDlg, oGroup, oBtn
do case
case nTheme == RB_THEME_DARK
oRb:oFont:End()
oRb:SetFont( TFont():New( "Segoe UI", 0, -14 ) )
oRb:nTopMargin := 50
oRb:nTop := 28
oRb:nHeight = 136
oRb:nHeightFld = 20
oRb:hSeparation = 4
oRb:nLeftMargin = 20
oRb:nRoundBox = 0
oRb:nClrPaneRB = RGB( 68, 68, 68 )
oRb:nClrBoxOut = RGB( 178, 178, 178 )
oRb:nClrBoxIn = RGB( 178, 178, 178 )
oRb:nClrBoxSelOut = RGB( 178, 178, 178 )
oRb:nClrBoxSelIn = RGB( 178, 178, 178 )
oRb:aGrad = { { 1, RGB( 178, 178, 178 ), RGB( 178, 178, 178 ) } }
oRb:aGradFld = { | nOpt | If( nOpt == oRb:nStart, { { 1, RGB( 178, 178, 178 ), RGB( 178, 178, 178 ) } },;
{ { 1, RGB( 178, 178, 178 ), RGB( 178, 178, 178 ) } } ) }
oRb:aGradHigh = { { 1, RGB( 178, 178, 178 ), RGB( 178, 178, 178 ) } }
oRb:aGradOver = { { 1, RGB( 0, 114, 198 ), RGB( 0, 114, 198 ) } }
AFill( oRb:aClrTabTxt, { | oSelf, nPrompt | If( nPrompt == oSelf:nOption, RGB( 0, 0, 0 ), RGB( 255, 255, 255 ) ) } )
DeleteObject( oRb:hBmpBrushEx )
DeleteObject( oRb:hBrushEx )
oRb:hBmpBrushEx = GradientBmp( oRb, oRb:nRight - oRb:nRightMargin - 3, oRb:nBottom - oRb:nTopMargin + 1, oRb:aGrad )
oRb:hBrushEx = CreatePatternBrush( oRb:hBmpBrushEx )
for each oDlg in oRb:aDialogs
oDlg:hBack = oRb:hBrushEx
oDlg:Refresh()
for each oGroup in oDlg:aControls
if oGroup:IsKindOf( "TRBGROUP" )
oGroup:oFont:End()
oGroup:SetFont( oRb:oFont )
oGroup:nHeight -= 24
oGroup:nClrBoxIn = RGB( 160, 160, 160 )
oGroup:aGradCaption = { { 1, RGB( 160, 160, 160 ), RGB( 160, 160, 160 ) } }
oGroup:bClrText = { | lEnable | If( lEnable, RGB( 0, 0, 0 ), GetSysColor( COLOR_GRAYTEXT ) ) }
oGroup:nClrBoxIn = RGB( 160, 160, 160 )
oGroup:nClrBoxOut = RGB( 160, 160, 160 )
DeleteObject( oGroup:hBrushSel )
DeleteObject( oGroup:hBrushUnSel )
DeleteObject( oGroup:hBack )
oGroup:hBrushUnSel = oDlg:hBack
oGroup:hBack = oDlg:hBack
for each oBtn in oGroup:aControls
if oBtn:IsKindOf( "TRBTN" )
oBtn:oFont:End()
oBtn:SetFont( oRb:oFont )
oBtn:nHeight -= 24
oBtn:bClrGradNormal = { | lPressed | If( lPressed, { { 1, RGB( 160, 160, 160 ), RGB( 160, 160, 160 ) } },;
{ { 1, RGB( 160, 160, 160 ), RGB( 160, 160, 160 ) } } ) }
oBtn:aClrGradUnder = { || { { 1, RGB( 160, 160, 160 ), RGB( 160, 160, 160 ) } } }
oBtn:aClrGradBack = { { 1, RGB( 160, 160, 160 ), RGB( 160, 160, 160 ) } }
oBtn:nClrBoxIn = RGB( 160, 160, 160 )
oBtn:nClrBoxOut = RGB( 160, 160, 160 )
endif
next
oGroup:Refresh()
endif
next
next
endcase
// oRb:Refresh()
oRb:Default()
return nil
//----------------------------------------------------------------------------//
